1.Please order 1 sample first before placing bulk orders (3+ items) to verify size & style and avoid return‑related inconvenience.

2.Our vent covers are sized based on duct opening dimensions (W x H: 10"x6"),not the outer decorative faceplate.

Neck Depth(D):1-3/4"D.Neck opening size(W x H):9-13/16"W x 3-15/16"H(the segment sliding inside ductwork).Face size(W x H):11-13/16"W x 5-7/8"H(the visible outer cover).

3.Pre-Purchase Checklist

Take down your existing vent cover and measure your duct opening.Confirm the duct cavity fits the insert neck (9-13/16"W x 3-15/16"H x 1-3/4"D). Watch out for blocking wall studs or sharp tapers that prevent full insertion.

Double-check the 11-13/16"W x 5-7/8"H faceplate can fully conceal your duct opening.If old mounting marks exceed the faceplate,use touch-up paint.Make sure mounting screws fasten firmly to the duct's inner edge.

4.Our product features concealed screw mounting, supplied with 4.5×50mm self-drilling screws. We recommend using an extended Phillips bit for installation.

5.Install screws at ≥45° away from duct openings to fasten into walls instead of duct edges. Pre-drill holes then use a long drillbit simplifies installation.

6.Air flowing through ductwork naturally creates soft low humming sounds.A loud whistling noise signals airflow issues:

(1)Confirm your HVAC unit operates within standard working parameters. (2)Open additional vents to balance system airflow. (3)Use the adjuster to fully fold this grille's adjustment blades for maximum air passage.

1.Please order 1 sample first before placing bulk orders (3+ items) to verify size & style and avoid return‑related inconvenience.

2.Our vent covers are sized based on duct opening dimensions (W x H: 10"x6"),not the outer decorative faceplate.

3.Pre-Purchase Checklist

4.Our product features concealed screw mounting, supplied with 4.5×50mm self-drilling screws. We recommend using an extended Phillips bit for installation.

5.Install screws at ≥45° away from duct openings to fasten into walls instead of duct edges.

6.Air flowing through ductwork naturally creates soft low humming sounds.
